IF1200A Pilot Operating Handbook 9. Battery Charging
Charge the Flight Batteries, Continued
Step
Action
5
Uncap the battery cable and plug it into the Power Interface port on the charger (see
below).
Note: The battery cable and Power Interface port on the charger are designed to
prevent incorrect mating of the two.
6
Locate the Balance Cable in the aircraft kit (see Figure 8, below).
NOTE: The balance cable for the IF1200A is different from the balance cable for
IF1200.
Figure 8. Balance Cable
IFT Doc Num 102094, Rev 1.02 Page 14
