IF1200A Pilot Operating Handbook 9. Battery Charging
Connect one end of the Balance Cable to the Balance Interface on the charger (see
Figure 7), and the other end to the Balance port on the battery.
Note: The white connector on the balance cable is not used during charging.
Once connected, the battery goes through a precharge countdown for 10 seconds,
then begins charging automatically.
Note: To skip the precharge countdown, hold the ‘Charge’ button for 2 seconds.
Cell voltages and battery levels are displayed on the LCD screen. When the batteries
are fully charged, each cell voltage should be about 4.20 Volts, and the charger will
display ‘Fully Charged’.
If you can’t wait for the batteries to fully charge, press the Charge button to
discontinue the charging process BEFORE unplugging the batteries.
DO NOT disconnect the battery cable from the charger while the
battery is charging. Doing so may result in electrical arcing,
causing severe burns to the operator.
IFT Doc Num 102094, Rev 1.02 Page 15
