IF1200A Pilot Operating Handbook 19. Disassemble and Store the Aircraft
Place the aircraft on a clean work surface.
Locate the case the IF1200A was originally packed in, and place it close at hand.
Remove the flight batteries.
Note: If the aircraft will be stored for a long period, connect the batteries to the
charger and set the charger to Storage mode.
In the following steps, begin with the arms that are NOT over the two Landing Gear
sockets. This allows you to leave the aircraft on its Landing Gear while working on it.
Attach a foam Propeller Holder onto an Arm, with the IFT logo facing the aircraft
body (except for the left-front Arm). Slide the Propeller Holder as close to the aircraft
body as possible.
Fold the propeller blades so they are pointing towards the aircraft body.
Slide the Propeller Holder outward along the Arm, guiding the propeller tips through
the hexagonal opening in the Propeller Holder. Slide the Propeller Holder further
outward until the propellers fit snugly in the Propeller Holder.
Figure 20. Detail of Propeller Holder Orientation
IFT Doc Num 102094, Rev 1.02 Page 42
