Inspired Flight IF1200A - Page 93

IF1200A Pilot Operating Handbook Appendix
Connect HereLink and QGroundControl through a WiFi Network
Step
Action
9
Enter a name for the Comm Link (see below). In this example, the name we
created is “IF1200A.”
10
Select Automatically Connect on Start.
11
In the Type field, select UDP.
12
In the Port field, verify it is set to 14550.
13
In the Server Addresses (Optional) field, enter the IP address of the Herelink (see
Step 1).
14
Click on OK at the bottom of the dialog box.
Continued next page
IFT Doc Num 102094, Rev 1.02 Page 90
