INSTEON 2457D2 - Understanding Linking; Links Are One-Way; Links Remember a Devices State; Controllers

6
When linking INSTEON devices, the links that
are created are one-way.
The current state of the controlled device is
stored in the link: on, o or dimmed.
Switch A will turn Switch B on and o but
Switch B cannot turn Switch A on or o.
The switch will turn on the Dimmer Module
to 75% brightness.
A SwitchB Dimmer Module
NEW
X
NEW
X
®
75%
d
f
h
a
c
e
g
b
INSTEON devices that can turn other devices
on or o are called controllers.
Sensors, Switches, Keypads and the
Hub are common controllers.
NEW
X
®
INSTEON devices that receive the command of a
controller are called responders.
Switches, LED Bulbs, Plug-In Modules and
Micro Modules are common responders.
NEW
X
®
RespondersControllers
Links Remember a Device’s StateLinks are One-Way
Understanding Linking
®
®
Neutral
On
Off
Set
N
N
Load L1
Line L
