Display and Control Elements
19
6 Display and Control Elements
Figure 1: Display and control elements on the front of the device
Position
Description
1
Reset key
2
Power LED
3
COM LED
4
Signal LED
5
Status LED
6
Activity LED for LAN ext.
7
Link LED for LAN ext.
8
Activity LED for LAN
9
Link LED for LAN
Table 3: Description of the display and control elements on the front panel of the device
