Integra 90520 - Electromagnetic Immunity Details; Conducted and Radiated RF Immunity; RF Communications Equipment Separation

17
Integra
®
LED Surgical Headlight System
Electromagnetic Compatibility (continued)
Table 204
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The Integra LED Surgical Headlight System is intended for use in the electromagnetic environment specified below. The
customer or user should insure that it is used in such an environment.
Immunity Test IEC 60601
Test Level
Compliance
Level
Electromagnetic Environment — Guidance
Conducted RF
IEC 61000-4-6
3 Vrms from
150 kHz to 80 Mhz
V1 = 3 Vrms Portable and mobile RF communications equipment should be no
closer to any part of the LED Surgical Headlamp System, including
cables, than the recommended separation distance calculated from the
equation applicable to the frequency of the transmier (distances 1.17
and 2.33).
Recommended separation distance:
d = [3.5/V1]√P
d = [3.5/E1]√P 80 MHz to 800 MHz
d = [3.5/E1]√P 800 MHz to 2.5 GHz
where P is the maximum output power rating of the transmier in
was (W) according to the transmier manufacturer and d is the
recommended separation distance in meters (m).
Field strengths from fixed RF transmiers, as determined by an
electromagnetic survey
a
, should be less than the compliance level in
each frequency range
b
.
Radiated RF IEC
61000-4-3
3 Vrms from 80
MHz to 2.5GHz
E1 = 3V/m
NOTE 1.
At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2.
These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from
structures, objects and people.
a
Field strengths from fixed transmiers, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess
the electromagnetic environment due to fixed RF transmiers, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the system under test is used exceeds the applicable RF compliance level
above, the system under test should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as reorienting or relocating the system under test.
b
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than [V1]V/m
