Electromagnetic Compatibility (EMC) User Information
Table 201
Guidance and Manufacturer’s Declaration – Emissions All Equipment and Systems
The Integra
®
LED Surgical Headlight System is intended for use in the electromagnetic environment specified below. The
customer or user should insure that it is used in such an environment.
Emissions Test Compliance Electromagnetic Enforcement -- Guidance
RF Emissions CISPR 11 Group 1 The Integra LED Surgical Headlight System uses RF energy only for its
internal function. Therefore, RF emissions are very low and are not likely
to cause any interference in nearby electronic equipment.
RF Emissions CISPR 11 Class B Radiated and
Conducted Emissions
The Integra LED Surgical Headlight System is suitable for use in all
establishments including domestic and those directly connected to the
public low voltage power supply network that supplies buildings used
for domestic purposes.
Harmonics IEC 61000-3-2 Class A
Voltage fluctuations/flicker
emissions IEC 61000-3-3
Complies
Table 202
Guidance and Manufacturer’s Declaration – Immunity All Equipment and Systems
The Integra LED Surgical Headlight System is intended for use in the electromagnetic environment specified below. The
customer or user should insure that it is used in such an environment.
Immunity Test IEC 60601
Test Level
Compliance
Level
Electromagnetic Environment --
Guidance
Electrostatic Discharge
(ESD) IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete, or
ceramic tile. If floors are synthetic, the
relative humidity should be at least 30%
Electrical Fast
Transient/burst IEC
61000-4-4
± 2 kV mains
± 1 kV I/O
± 2 kV mains
Not applicable
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge IEC 61000-4-5 ±1 kV Differential
± 2 kV Common
±1 kV Differential
± 2 kV Common
Mains power quality should be that
of a typical commercial or hospital
environment.
For Direct Power (AC) Operation:
Voltage dips, short interruptions
and voltage variations on power
supply input lines IEC 61000-4-11
>95% Dip for 0.5
Cycle
60% Dip for 5 Cycles
30% Dip for 25 Cycles
>95% Dip for 5 sec
>95% Dip for 0.5
Cycle
60% Dip for 5 Cycles
30% Dip for 25 Cycles
>95% Dip for 5 sec
Mains power quality should be that
of a typical commercial or hospital
environment. If the user requires
continued operation during power mains
interruptions, it is recommended that the
unit be powered from an uninterruptable
power supply or baery accessory.
Power Frequency
50/60 Hz Magnetic Field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should
be that of a typical commercial or
hospital environment.
