16
En
Bi-amping the Front Speakers
Bi-amping provides improved bass and treble performance.
When bi-amping is used, the AV controller is able to drive up to a 7.2 speaker system in the main room.
Once you’ve completed the bi-amping connections as shown and turned on the AV controller, you must set the speaker
setting to enable bi-amping (➔ page 52).
See your multichannel power amplifier’s instruction manual for more information on connecting speakers.
■ Connection via RCA Jacks
Important:
• When making the bi-amping connections, be sure to remove the jumper bars that link the speakers’ tweeter (high) and woofer (low)
terminals.
• Bi-amping can be used only with speakers that support bi-amping. Refer to your speaker manual.
Multichannel
power amplifier
Front right Front left
Tweeter (high)
Woofer (low)
AV controller
To Next Page
