Integra DRX-5 Basic Manual

3
|
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting Appendix
70 m or less in length)
■ Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX)
■ Compatible input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
Component input
480i/576i
Composite input
480i/576i
•
The output from the HDMI OUT jack to the TV is the
same resolution as the input. When using a TV that
supports 4K, 1080p HDMI video signals can also be
output as 4K.
■ Audio Inputs
Digital
OPTICAL 1 (CD), 2 (TV)
COAXIAL (BD/DVD)
Analog
BD/DVD, CBL/SAT, GAME, STRM BOX, CD, TV,
PHONO
■ Audio Outputs
Analog
ZONE2 PRE/LINE OUT
ZONE3 PRE/LINE OUT
PRE OUT (FRONT L/R, CENTER, SURROUND L/R,
BACK or HEIGHT L/R, 2 SUBWOOFER)
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT L/R or Bi-Amp L/R
or ZONE2B L/R, ZONE2A L/R
(North American models are banana plug ready)
Phones
PHONES (Front, ø 6.3 mm, 1/4")
■ Others
Setup Mic : 1 (Front)
USB : 1 (Ver. 2.0, 5 V/1 A)
Ethernet : 1
RS232 : 1
12V TRIGGER OUT : (A: 100 mA, B: 25 mA, C: 25 mA)
IR IN : 2 (A/B)
IR OUT : 1
■ Power consumption in standby mode
•
In the following cases, the power consumption in
standby mode may reach up to a maximum of 12 W:
–
When "Network Standby" is set to "On"
–
When "HDMI CEC" is set to "On"
–
When "HDMI Standby Through" is set to other than
"Off"
–
When "USB Power Out at Standby" is set to "On"
Specifications and features are subject to change without
notice.
