46
En
■ Speakers Type (Front)
` Normal
:
Select this if you’ve connected your front speakers
normally.
` Bi-Amp:
Select this if you’ve bi-amped your front speakers.
Note
• Powered Zone 2 cannot be used if “Speakers Type (Front)” is
set to “Bi-Amp” (➔ 62)
.
■ Speaker Terminal Assign
Front High/Front Wide/Zone 2
With this setting, you can specify the speakers connected
to Front High/Front Wide/Zone 2 speaker terminals.
` Front High
:
Front high speakers can be used.
` Front Wide:
Front wide speakers can be used.
` Zone 2:
Zone 2 speakers can be used. (Powered Zone 2
enabled).
Note
•If the “Speakers Type (Front)” setting is set to “Bi-Amp”, or
Powered Zone 2 cannot be used.
•If “Front Wide” is selected in the “Surr Back/Front High/
Front Wide” setting, you cannot select “Front Wide” here.
Surr Back/Front High/Front Wide
With this setting, you can specify the speakers connected
to Surr Back/Front High/Front Wide speaker terminals.
` Surr Back
:
Surround back speakers can be used.
` Front High:
Front high speakers can be used.
` Front Wide:
Front wide speakers can be used.
Note
•If the “Speakers Type (Front)” setting is set to “Bi-Amp”, or
Powered Zone 2 cannot be used.
•If “Front High” is selected in the “Front High/Front Wide/
Zone 2” setting, you cannot select “Front High” here.
•If “Front Wide” is selected in the “Surr Back/Front High/
Front Wide” setting, you cannot select “Front Wide” here.
Speaker Configuration
With these settings, you can specify which speakers are
connected and a crossover frequency for each speaker.
Specify “Full Band” for speakers that can output low fre-
quency bass sounds adequately, for example, speakers
with a good sized woofer. For smaller speakers, specify a
crossover frequency. Sounds below the crossover fre-
quency will be output by the subwoofer instead of the
speaker. Refer to your speaker’s manuals to determine the
optimum crossover frequencies. If you set up your speak-
ers using Audyssey 2EQ
®
Room Correction and Speaker
Setup, please make sure manually that any THX speakers
are set to “80Hz(THX)” crossover.
■ Subwoofer
` Ye s
:
Select if a subwoofer is connected.
` No:
Select if no subwoofer is connected.
■ Front
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
Note
•If the “Subwoofer” setting is set to “No”, the “Front” setting is
fixed at “Full Band”.
■ Center
*1
, Surround
*1
, Surr Back
*2*3*4*5
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
` None:
Select if no speaker is connected.
■ Front Wide
*1*2*4*6
, Front High
*1*2*4*7
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
` None
:
Select if no speaker is connected.
Note
*1
“Full Band” can be selected only when “Full Band” is
selected in the “Front” setting.
*2
If the “Surround” setting is set to “None”, this setting cannot
be selected.
*3
If the “Surround” setting is set to anything other than “Full
Band”, “Full Band” cannot be selected here.
*4
If the “Speakers Type (Front)” setting is set to “Bi-Amp”
(➔ 46), or Powered Zone 2 is being used (➔ 62), this setting
cannot be selected.
*5
If you have selected other than “Surr Back” in the “Surr
Back/Front High/Front Wide” setting, this setting cannot be
selected.
*6
If you have selected other than “Front Wide” in the “Front
High/Front Wide/Zone 2” or “Surr Back/Front High/Front
Wide” setting, this setting cannot be selected.
*7
If you have selected other than “Front High” in the “Front
High/Front Wide/Zone 2” or “Surr Back/Front High/Front
Wide” setting, this setting cannot be selected.
■ Surr Back Ch
` 1ch:
Select if only one surround back speaker L is con-
nected.
` 2ch
:
Select if two (left and right) surround back speakers
are connected.
Note
•If the “Surr Back” Setting is set to “None” (➔ 46), this setting
cannot be selected.
■ LPF of LFE
(Low-Pass Filter for the LFE Channel)
` 80Hz, 90Hz, 100Hz, 110Hz, 120Hz
With this setting, you can specify the cutoff frequency
of the LFE channel’s low-pass filter (LPF), which can
To Next Page
