The following tables show how video signals at different resolutions are output by the AV receiver.
NTSC/PAL
✔: Output
*1
Available resolutions: [640 × 480 60 Hz], [800 × 600 60 Hz], [1024 × 768 60 Hz], [1280 × 1024 60 Hz]
*2
Available resolutions: [3840 × 2160 24/25/30 Hz]
*3
If you connect your TV to the HDMI OUT SUB, HDMI signals are output with no conversion.
*4
When video signals of personal computers connected to PC IN are output from HDMI OUT SUB, they may not display properly on
some TVs.
*
The on-screen menus and superimposed menus are displayed via HDMI OUT MAIN.
Video Resolution Chart
HDMI
*3
4K
*2
1080p/24 1080p 1080i 720p 480p/576p 480i/576i
HDMI 1080p ✔✔
✔
*3
1080i ✔✔✔
✔
*3
✔
720p ✔✔✔✔
✔
*3
480p/576p ✔✔✔✔✔
✔
*3
480i/576i ✔✔✔✔✔✔
✔
*3
Component 1080p ✔✔✔
1080i ✔✔✔✔✔
720p ✔✔✔✔✔
480p/576p ✔✔✔✔✔✔
480i/576i ✔✔✔✔✔✔✔
S-Video
Composite
480i/576i ✔✔✔✔✔✔✔
PC IN (Analog RGB)
*1*4
✔✔✔✔✔✔
Component S-Video
Composite
1080p 1080i 720p 480p/576p 480i/576i 480i/576i
HDMI 1080p
1080i
720p
480p/576p
480i/576i
Component 1080p ✔
1080i ✔
720p ✔
480p/576p ✔
480i/576i ✔
S-Video
Composite
480i/576i ✔
PC IN (Analog RGB)
*1*4
Output
Input
Output
Input
