Appendix
En-101
*1
The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a
microwave oven, static electricity, cordless phone,
reception sensitivity, antenna’s performance, operating
system, software application, etc.
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Compatible Bluetooth profiles
A2DP 1.2 (Advanced Audio Distribution
Profile)
AVRCP 1.3 (Audio Video Remote
Control Profile)
Supported Codecs SBC
Transmission range (A2DP)
20 Hz – 20,000 Hz (Sampling frequency
44.1 kHz)
Power Supply AC 120 V, 60 Hz (North American)
AC 220 - 240 V, 50/60 Hz (Australian)
Power Consumption 6.9 A (North American)
690 W (Australian)
No-sound Power Consumption
80 W (North American)
75 W (230 V)
80 W (240 V)
(Australian)
Stand-by Power Consumption
0.1 W (North American)
0.2 W (Australian)
Dimensions (W × H × D)
435 mm × 175 mm × 376 mm
17-1/8" × 6-7/8" × 14-13/16"
Weight 11.4 kg (25.1 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6, IN 7,
AUX INPUT
Output OUT MAIN, OUT SUB
Video Resolution 4K
Audio Format Dolby TrueHD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, LipSync, CEC (RIHD), 4K (up-
scaling and Passthrough)
Component IN 1, IN 2
Composite IN 1, IN 2, IN 3, IN 4, AUX
Component OUT
Composite MONITOR OUT
Digital Optical: 1
Coaxial: 2
Analog BD/DVD, CBL/SAT, STB/DVR, GAME,
PC, TV/CD, PHONO, AUX
Analog ZONE2 PRE/LINE OUT, ZONE3 PRE/
LINE OUT
Multichannel Pre Outputs
7 (L, R, C, SL, SR, SBL or FHL, SBR or
FHR)
Subwoofer Pre Outputs
2
Speaker Outputs Main (L, R, C, SL, SR, SBL/FHL,
SBR/FHR) + ZONE2 (L, R)
Phones 1 (ø 6.3)
Setup Mic 1
RI 1
RS232 1
USB 1 (Front)
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out 3
