Appendix
En-100
Specifications
Amplifier Section
Video Section
Tuner Section
Network Section
Bluetooth Section
The Bluetooth
®
word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Onkyo is under license. Other trademarks
and trade names are those of their respective owners.
Onkyo does not guarantee Bluetooth compatibility between
the AV receiver and all Bluetooth-enabled devices.
For compatibility between the AV receiver and another
device with Bluetooth technology, consult the device’s
documentation and dealer. In some countries, there may
be restrictions on using Bluetooth devices. Check with your
local authorities.
Rated Output Power
All channels: 110 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08% (FTC)
125 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
(North American)
7 ch × 170 W at 6 ohms, 1 kHz, 1 ch
driven of 1% (IEC)
(Australian)
Maximum Effective Output Power
7 ch × 185 W at 6 ohms, 1 kHz, 1 ch
driven (JEITA)
(Australian)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
250 W (3 Ω, Front)
220 W (4 Ω, Front)
130 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
200 mV/470 Ω (PRE OUT/LINE OUT)
Maximum RCA Output Level and Impedance
4.6 V/470 Ω (PRE OUT/LINE OUT)
Phono Overload 70 mV (MM 1 kHz 0.5% Direct)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (Direct
mode)
Tone Control Characteristics
±10 dB, 30 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
Speaker Impedance 4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB,
PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American)
87.5 MHz - 108.0 MHz, RDS (Australian)
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Ethernet LAN 10BASE-T/100BASE-TX
Wireless LAN
Compatible standards:
IEEE 802.11 b/g/n standard (Wi-Fi
®
standard)
Security: WEP 64 bit, WEP 128 bit, WPA/WPA2-
PSK (AES), WPA/WPA2-PSK (TKIP)
Transmission frequency
1 - 11 ch (North American)
1 - 13 ch (Australian)
(Wi-Fi
®
standard)
Radio frequency 2.4 GHz
Communication system
Bluetooth Specification version 2.1 +
EDR (Enhanced Data Rate)
Maximum communication range
Line of sight approx. 15 m
*1
Frequency band 2.4 GHz band (2.4000 GHz –
2.4835 GHz)
Modulation method FHSS (Freq Hopping Spread Spectrum)
