DTR-5.9
DEBUG MODE-6
HDMI DEBUG MODE-2/2
Source Device Video Format : OK,
Sink Device EDID : OK
i/p/I/P
Source Device Video Format : OK,
Sink Device Hot plug : Low
Source Device Video Format : OK,
Sink Device HDCP Authenification : Fail
Source Device Video Format : OK,
Sink Device Busy (Cannot accept HDMI signal)
VGA input via DVI-HDMI conversion cable
VGA input via HDMI cable
Video signal route :
HDMI Through
Video signal route :
Via Video Signal Processor
Source Device
Video resolution is
not Determined
Source video Format :
PC Format
Frame Rate
Input
Horizontal Resolution
Error State ---> Remedy
6
Error State ---> Remedy
7
Input
Vertical Resolution
Normal State
Normal State
Normal State
Error State ---> Remedy
8
Error State ---> Remedy
10
Error State ---> Remedy
9
Video Input Format Status Description
0 1 2 3 4 5 6 7 8 9 10 11 12
13 14
FL segment No. --->
Description --->
<Notes>
In the case that horizontal resolution is doubled, “ # ” is marked at the head of the resolution.
In the case that horizontal resolution is quadrupled, “ ” is marked at the head of the resolution.
Resolution example : 480p, 576p, 480i, 576i, 240p, 288p
Source device example : Panasonic DVD player’s Double Resolution of 480p.
Blue-ray player’s Quadruple Resolution of 480p when TrueHD etc. is played back.
Remedy for Error State
Remedy No. Remedy
The most possible cause is the hardware trouble of Sink device. Fix it.
Refer to HDCP and Authentification error in “DEBUG MODE-7”. Follow the procedure.
Refer to Resolution error in “DEBUG MODE-7”. Follow the procedure.
Refer to EDID error in “DEBUG MODE-7”. Follow the procedure.
Check other HDMI Inputs of AV receiver. If NG, the most possible cause is the hardware trouble of Sink device. Fix it.
Check Source device output signal. No signal, or the format is not supported by both HDMI and AV receiver.
The same as .
The most possible cause is the hardware trouble of Sink device. Fix it.
The same as .
The same as .
