38/98 PAGE
PCB2
JL6016B WIRE TRAP NPLG-11P594 1 25055632
PCB2
JL6017B WIRE TRAP NPLG-3P586 1 25055624
PCB2
JL6065B WIRE TRAP NPLG-9P592 1 25055630
PCB2
JL6605 JUMPER LEAD JL5 400 H 1 ---
NSP
PCB2
JL6605A WIRE HOL NSCT-5P896 1 25051109
PCB2
JL7101 JUMPER LEAD JL7 200 H 1 ---
PCB2
JL7101A WIRE HOL NSCT-7P898 1 25051111
PCB2
JL7352 JUMPER LEAD JL5 600 B 1 ---
NSP
PCB2
JL7352A WIRE HOL NSCT-5P876 1 25051089
PCB2
JL7352B WIRE TRAP NPLG-5P588 1 25055626
PCB2
JL7353 JUMPER LEAD JL3 200 H 1 ---
NSP
PCB2
JL7353A WIRE HOL NSCT-3P894 1 25051107
PCB2
JL7353B WIRE HOL NSCT-3P894 1 25051107
PCB2
JL9101 JUMPER LEAD JL7 350 H 1 ---
NSP
PCB2
JL9101A WIRE HOL NSCT-7P898 1 25051111
PCB3
U32
MICROPROCESSOR PC BOARD (NADG-9462-1U / 1V)
PCB3
PCB3
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB3
U301 PHT CP JSR1165-001recieving 1 24120143
PCB3
U301 or PHT CP GP1FAV51RK0F (1) 24120129
PCB3
U302 PHT CP JSR1165-001recieving 1 24120143
PCB3
U302 or PHT CP GP1FAV51RK0F (1) 24120129
PCB3
U303 PHT CP GP1FAV51TKBF 1 24120132
PCB3
U303 or PHT CP JST1165-001transmitting (1) 24120142
PCB3
Q301 IC CS42518-CQZR-D 1 22242229R2
PCB3
Q302 IC TC74VHC157FT 1 22274157ER2TO
PCB3
Q303 IC TC7WU04FU(TE12L_F) 1 22240935R2
PCB3
Q304 IC 74HCU04F 1 222740046R2
PCB3
Q305 IC NJM2860F3-33 1 22242087R2
PCB3
Q306 IC NJM4580M-D 1 22241448R2
PCB3
Q307 TR 2SC2235-Y(TPE6_F) 1 2211654T
PCB3
Q401 IC NJM4580M-D 1 22241448R2
