PRINTED CIRCUIT BOARD-PARTS LIST
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta
rou
hFE
as
the original type.
NOTE:
<D>:120V model onl
<A>: Australian model only
DISPLAY CIRCUIT PC BOARD
NADIS-7738-2E/2F
CIRCUIT NO. PART NO. DESCRIPTION
FL tube
Q7501 212245 or 16-BT-115GNK or
212234 HNA-16MM40T
ICs
Q7201 22242003R3W M30626FHPFP
Q7502 22241680AR2 M66005-0001AFP
Remote sensor
U7201 241352 SPS-444-1-VP
Transistors
Q7202 2216230R2 or KRA103S or
2214540R2 RN2403
Q7503,Q7504 2216175R2 or KTC3875-GR or
Q7536,Q7537 2213145R2 2SC2712-GR
Q7521~Q7527 2216190R2 or KRC102S or
Q7529~Q7535 2214470R2 RN1402
Diodes
D7201,D7202 223234R2 or 1SS352 or
D7502 223269R2 1SS355
D7203 224490510R2 or UDZ5.1B or
224550510R2 UDZS5.1B,Zener
D7501 224491100R2 or UDZ11B or
224551100R2 UDZS11B,Zener
D7521~D7527 225375 SML1216C
D7529~D7532 225375 SML1216C
D7533 225290 SEL4110R
D7534 225292D SEL4310G-D
D7535 225374 SEL2E10C
Coils
L7201 231237M022R2 or NCH-1471 or
233533M022R2 NCH-1587-022M
R7201,R7202 230958R1 BK1608LM182-T
