Integra DTR-8.4 - Zone 2-Continued; Controlling Zone 2

Oscillator
X7201 3010322 CST16.00MXW0C1
Ca
p
acitors
C2577,C2578 332161040R1 CK725F1E-104Z1, Ceramic
C7201,C7202 355721019 CE04W6.3V-100M,Elect.
C7203 375524744 MMT50V-474J,Plastic film
C7204,C7206 332174740R1 CK725F1C-474Z1,Ceramic
C7207 355721019 CE04W6.3V-100M,Elect.
C7208 332161040R1 CK725F1E-104Z1, Ceramic
C7213,C7214 332101025R1 CK725B1H-102K1,Ceramic
C7293~C7295 332101025R1 CK725B1H-102K1,Ceramic
C7297 332101025R1 CK725B1H-102K1,Ceramic
C7501,C7502 332174740R1 CK725F1C-474Z1,Ceramic
C7503 354721019S CE04W6.3V-100M,Elect.
C7504,C7508 342101014R1 CC725CH1H-101J1,Ceramic
C7505,C7507 332161040R1 CK725F1E-104Z1, Ceramic
C7506 375524744 MMT50V-474J,Plastic film
C7509 332174740R1 CK725F1C-474Z1,Ceramic
C7510 355783309 CE04W50V-33M,Elect.
CIRCUIT NO. PART NO. DESCRIPTION
Resistors
R7203~R7207 435031024R1 RN72K1J-102JE,Carbon
R7209~R7212 435031024R1 RN72K1J-102JE,Carbon
R7218,R7219 435031034R1 RN72K1J-103JE,Carbon
R7220,R7263 435031024R1 RN72K1J-102JE,Carbon
R7229,R7230 435032214R1 RN72K1J-221JE,Carbon
R7231~R7234 435031014R1 RN72K1J-101JE,Carbon
R7235~R7238 435032214R1 RN72K1J-221JE,Carbon
R7239,R7240 435031034R1 RN72K1J-103JE,Carbon
R7242,R7243 435031034R1 RN72K1J-103JE,Carbon
R7245 435031034R1 RN72K1J-103JE,Carbon
R7247,R7248 435031034R1 RN72K1J-103JE,Carbon
R7249,R7250 435033314R1 RN72K1J-331JE,Carbon
R7251~R7256 435031034R1 RN72K1J-103JE,Carbon
R7258~R7260 435031034R1 RN72K1J-103JE,Carbon
R7271 435031034R1 RN72K1J-103JE,Carbon
R7272 435032214R1 RN72K1J-221JE,Carbon
R7275 435034724R1 RN72K1J-472JE,Carbon
R7279,R7280 435031024R1 RN72K1J-102JE,Carbon
R7282,R7284 435031034R1 RN72K1J-103JE,Carbon
R7286 435031034R1 RN72K1J-103JE,Carbon
