Intel 1037U User Manual

12
(6) JCOM1 (6-pin): COM1 Port RS232/RS485/RS422 Function Select
3-4 Closed : RS485;
JCOM1→COM1 Port
1-2 Closed: RS232;
5-6 Closed : RS422.
1 1 1
(7)AT_MODE1 (2-pin): AT Mode Function Select
1-2 Short： AT_Mode Select.
AT_MODE1
1-2 Open： Normal;
Pin 1-2 closed: AT_MODE function is enabled. In this case your computer will
automatically turns on after a sudden power failure when power supply resumes.

Intel 1037U Specifications

General

CPU Series	Intel Celeron
CPU Model	1037U
Cores	2
Threads	2
Clock Speed	1.8 GHz
TDP	17 W
Cache	2 MB
Max Memory Size	16 GB
Graphics Base Frequency	350 MHz
Graphics Max Dynamic Frequency	1.0 GHz
PCI Express Revision	2.0
SATA Ports	2
Instruction Set	64-bit
Socket	BGA1023
Integrated Graphics	Intel HD Graphics
Memory Type	DDR3
CPU Socket	FCBGA1023
Memory Types	DDR3 1333/1600
USB Revision	3.0
Instruction Set Extensions	SSE4.1/4.2
