Intel 1037U User Manual

33
3-8 Chipset Menu
 South Bridge Configuration
Press [Enter] to make settings for the following sub-items:
Onboard PCIE LAN2
Use this item to control the onboard PCIE LAN2 root port.
The optional settings are: [Disabled]; [Enabled].
MINI_CARD
Use this item to control the MINI_CARD.
The optional settings are: [Disabled]; [Enabled].
When set as [Enabled], user can make settings in ‘PCIe Speed’ that appears:
PCIe Speed
Use this item to select PCIE speed for MINI_CARD slot.
The optional settings are: [Auto]; [Gen1]; [Gen2].

Intel 1037U Specifications

General

CPU Series	Intel Celeron
CPU Model	1037U
Cores	2
Threads	2
Clock Speed	1.8 GHz
TDP	17 W
Cache	2 MB
Max Memory Size	16 GB
Graphics Base Frequency	350 MHz
Graphics Max Dynamic Frequency	1.0 GHz
PCI Express Revision	2.0
SATA Ports	2
Instruction Set	64-bit
Socket	BGA1023
Integrated Graphics	Intel HD Graphics
Memory Type	DDR3
CPU Socket	FCBGA1023
Memory Types	DDR3 1333/1600
USB Revision	3.0
Instruction Set Extensions	SSE4.1/4.2
