Intel 1037U - Headers

15
2-2-2 Headers
(1) JW-FP1 (9-pin): Front Panel Header
HDDLED+
GND
PWRLED+
GND
PWRLED-
HDDLED-
RSTSW
PWRBTN
Pin 1
2
(2) USB2/USB3 (9-pin): USB 2.0 Port Header
Pin 1
VCC
-DATA
GND
+DATA
VCC
NC
-DATA
GND
+DATA
