Intel 1037U User Manual

2
1-2 Specification
Spec Description
Design

6-layer PCB size: 16.8 x 12.0 cm
Embedded CPU 
Intel
®
1037U Dual Core CPU (1.8GHz)
Chipset

Intel
®
NM70 Express Chipset
Memory

1* DDRIII SO-DIMM slot to support DDRIII 1066/1333 MHz
DDRIII SO-DIMM expandable to 8GB

NL70-IE1037-2G: onboard 2G DRAM
Expansion Slot

1 *halt-size Mini-PCIE slot

1* SIM slot
Storage

2* SATA II 3G/s Connector

1 * M-SATA Connector
LAN Chip

Integrated with Realtek RTL8111G PCI-E Gigabit LAN
chip

Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
Audio Chip

Realtek ALC887 HD Audio Codec integrated

Audio driver and utility included
BIOS

32M DIP Flash ROM
Multi I/O
Rear Panel I/O:

1* COM Port

1 * VGA port

2* USB 2.0/1.1 port

2* RJ-45 port

1* Line-Out port
Internal I/O Connectors& Headers:

1 *4-pin 10V~24V Internal Power connector

1 *4-pin SATA Power connector

1 * Front panel header

2 * 9-Pin USB 2.0/1.1 header for four USB 2.0/1.1 ports

Intel 1037U Specifications

General

CPU Series	Intel Celeron
CPU Model	1037U
Cores	2
Threads	2
Clock Speed	1.8 GHz
TDP	17 W
Cache	2 MB
Max Memory Size	16 GB
Graphics Base Frequency	350 MHz
Graphics Max Dynamic Frequency	1.0 GHz
PCI Express Revision	2.0
SATA Ports	2
Instruction Set	64-bit
Socket	BGA1023
Integrated Graphics	Intel HD Graphics
Memory Type	DDR3
CPU Socket	FCBGA1023
Memory Types	DDR3 1333/1600
USB Revision	3.0
Instruction Set Extensions	SSE4.1/4.2
