34 Intel
®
440Bx Scalable Performance Board Development Kit Manual
Hardware Reference
4.5.9 PCI Slot Connector
Table 13. PCI Slots (J7, J8, J9)
Pin Signal Name Pin Signal Name Pin Signal Name Pin Signal Name
A1 VCC B1 - 12V A32 AD16 B32 AD17
A2 + 12V B2 GND A33 3.3V B33 CBE2#
A3 VCC B3 GND A34 FRAME# B34 GND
A4 VCC B4 No Connect A35 GND B35 IRDY#
A5 VCC B5 VCC A36 TRDY# B36 3.3 V
A6 PIRQ1# B6 VCC A37 GND B37 DEVSEL#
A7 PIRQ3# B7 PIRQ2# A38 STOP# B38 GND
A8 VCC B8 PIRQ0 A39 3.3 V B39 LOCK#
A9 No Connect B9 PRSNT1B# A40 SDONE B40 PERR#
A10 VCC B10 No Connect A41 SBO# B41 3.3 V
A11 No Connect B11 PRSNT2B# A42 GND B42 SERR#
A12 GND B12 GND A43 PAR B43 3.3V
A13 GND B13 GND A44 AD15 B44 CBE1#
A14 No Connect B14 No Connect A45 3.3V B45 AD14
A15 RST# B15 GND A46 AD13 B46 GND
A16 VCC B16 PCLK3 A47 AD11 B47 AD12
A17 GNT1# B17 GND A48 GND B48 AD10
A18 GND B18 REQ# A49 AD9 B49 GND
A19 Reserved B19 VCC A50 KEY B50 KEY
A20 AD30 B20 AD31 A51 KEY B51 KEY
A21 3.3V B21 AD29 A52 CBEO# B52 AD8
A22 AD28 B22 GND A53 3.3 V B53 AD7
A23 AD26 B23 AD27 A54 AD6 B54 3.3 V
A24 GND B24 AD25 A55 AD4 B55 AD5
A25 AD24 B25 3.3 V A56 GND B56 AD3
A26 IDSEL B26 CBE3# A57 AD2 B57 GND
A27 3.3V B27 AD23 A58 AD0 B58 AD1
A28 AD22 B28 GND A59 VCC B59 VCC
A29 AD20 B29 AD21 A60 REQ64# B60 ACK64#
A30 GND B30 AD19 A61 VCC B61 VCC
A31 AD18 B31 3.3 V A62 VCC B62 VCC
