440Bx Scalable Performance Board Development Kit Manual 59
Bill of Materials B
Table 18 is the bill of materials for the baseboard. Table 19 is the bill of materials for the processor
assembly.
Table 18. Baseboard Bill of Materials (Sheet 1 of 5)
Rev. 1.7
Reference
Designator
Description Manufacturer
Manufacturer
P/N
Comments/
Changes
from
Rev D
Alternate
Manufacturing
Info
All
Changes
J14,J15
Conn,Jumper2,1X2 25-mil
sq/100-mil space,HDR2
3M 929647-09-02
J20-24
Conn,Jumper3,1X3 25-mil
sq/100-mil space,HDR3
3M 929647-09-03
J12 Conn,Fan AMP 173981-3
XU9 PLCC, Socket 28 AMP 822271-1
J19
Conn,CPU,400 Pin Array
(BGA),BGA40X10-400R
Berg 74219-002
U6
IC,Clock
Generator,CK100,SSOP300
-48(PIN)
Cypress CY2280PVC-11S
U16
IC,Clock Buffer,18 Output
low skew,SSOP300-48(PIN)
Cypress
CY2318ANZPVC-
1
Y2
Crystal,32.768KHz,XTAL/
MC-405
Epson MC-405
J4 Conn, Serial Stack,DB9MX2 FOXCONN DM10156-73
J3 Conn, DB25,DB25FM1 FOXCONN DT11323-R5T
J7,J8,J9
Conn,PCI Edge
Recept,145154-120
FOXCONN EH06001-PC-W
J5,J6
Conn,ISA Edge Recept.,isa-
98
FOXCONN EQ04901-S6
JP1 Conn,Floppy,17X2 Header FOXCONN HL07173-P4
JP3,JP4 Conn, IDE,20X2 Header FOXCONN HL07206-D2
J11
Conn,Power,5566DP-20/
ATX
FOXCONN HM20100-P2
J1
Conn,PS2 Keyboard /
Mouse Connector
FOXCONN MH11067-D2
J13
Conn,AGP Edge Recept.,
120 pins,AGP-124
FOXCONN PC1243K-10
J2 2 USB Stack Connectors FOXCONN UB1112C-D3
U11
BIOS FLASH
Memory,TSOP12X20/40S
INTEL E28F004B5T60
Part #
changed in
previous
rev
U8
VLSI,PIIX4,PCI to IDE &ISA
Bridge,324
mBGA,BGA20x20-324
Intel FW82371EB
