Intel 440BX Manual&Nbsp;

64 Intel
®
440Bx Scalable Performance Board Development Kit Manual
Bill of Materials
Table 19. PGA370 Socket Processor Assembly Bill of Materials (Sheet 1 of 3)
Rev. 4.6
Reference
Designator
Description Manufacturer Manufacturer P/N
Alternate
Manufacturing
Info
All Changes
R54,R66,R79 0, CR0805 PANASONIC ERJ-6GEY0R00V
DALE -
CRCW0805000ZT
R68,R71,R72 2.2, CR1206 PANASONIC ERJ-8RQJ2R2V
R63,R65 10, CR0805 PANASONIC ERJ-6GEYJ100V
Q1,Q2,Q3,Q4
N DGS, 25V, SOT-
23
FAIRCHILD FDV301N
Changed Part #
and renumbered
transistors
C84,C85,C94,C95,C
96, C97,C98
0.01uF, 10V,
CC0603
PANASONIC ECJ-1VB1A103K
KEMET -
C0603C103K8R
C145,C146 0.1uF, 25V, CC603 PANASONIC ECJ-1VB1E104K
MURATA -
GRM39Y5V104Z0
25AD
C3,C4,C5,C6,C7,C8,
C9,
C66,C67,C68,C69,C
70,
C71,C72,C73,C74,C
75,
C76,C77,C78,C79,C
80,
C81,C82,C83,C89,C
90,
C91,C92,C93,C101,
C102,C103,C106,C1
10,C113,
C115,C128,C129,C1
31,
C132,C147,C149,C1
51, C152,C153, C154
0.1uF, 16V,
CC0603
PANASONIC ECJ-1VB1C104K
KEMET -
C0603C104K4R
C137,C138 0.1uF, 25V, 805 MURATA
GRM40X76104K0
25AD
KEMET -
C805C104K3RAC
(USE ANY
VOLTAGE ABOVE
16V)
R61
1.00K 1%,
CR0805
PANASONIC ERJ-6ENF1001V
R86,R87,R90,R91,R
106, R107
1.5K, CR0805 PANASONIC ERJ-6GEYJ152V
C150
10 pf, 50V,
CC0603
PANASONIC ECU-V1H100DCM
KEMET -
C0603C100K5G
R60 100 1%, CR0805 PANASONIC ERJ-6ENF1000V
R70,R78,R88,R92 10K, CR0805 PANASONIC ERJ-6GEYJ103V
RP64 10K, EXB-V PANASONIC EXB-V8V103JV
R97,R101
110 ohm 1%,
CR0805
PANASONIC ERJ-6ENF1100V
R57,R58,R59 150 1%, CR0805 PANASONIC ERJ-6ENF1500V
R47,R96,R98,R108,
R109, R110
150 ohm, CR0805 PANASONIC ERJ-6GEYJ151V

Intel 440BX Specifications

General

Brand	Intel
Model	440BX
Category	Motherboard
Language	English
