440Bx Scalable Performance Board Development Kit Manual 61
Bill of Materials
U9 IC,PLD,PLCC28,Socket28 LATTICE GAL22V10B-7LJ
U23
IC,Linear Voltage
Regulator,SOT-223
Linear Tech. LT1117-3.3cst
U5
IC,Linear Voltage
Regulator,SOT-223
Linear Tech. LT1117CST
XU11
40TSOP BIOS
Socket,TSOP12X20/40S
Meritec 980020-40-01
XU12,XU13 TIL311 SOCKET,DIP14 MILLMAX
110-99-314-41-
001
U25 IC,Logic,74ACT05,SO14 Motorola MC74ACT05DR
FB1-FB-4,
FB9
Ferrite Bead, SM1806, Z-
Bead
Murata BLM41P750S
Changed
part # on
Rev. 1.7
FB5,FB6,FB
7,FB8
Ferrite Bead, SM1806, Z-
Bead
Murata BLM41A800S
U22 IC,Logic,74ALS00,SOIC14 National DM74ALS00M
U7
IC,Tranciever,8-Bit Bidirec-
tional
Buffer,SOIC20,SO20W
National
DM74ALS245AW
M
C69,C83,C9
8,C110
Cap,Electrolitic,220uF,
25v,6.3mmx11.2mm,PCAPR
200-300
Panasonic ECE-A1EU221
R48,R52,R9
8-R100,
R106,R108-
R116,R118-
R122
Chip Resistor,0 Ohm
Shunt,5%,CR0805
Panasonic ERJ6GEY0R00V
R25,R42,R4
5,R49,R63,R
101,R102
Chip
Resistor,1K,5%,CR0805
Panasonic ERJ6GEYJ102V
R2,R4,R5,R1
1,R40,R41,R
43,R53-
R56,R105,R
117,R123-
124,R127
Chip
Resistor,10K,5%,CR0805
Panasonic ERJ6GEYJ103V
R1,R3,R88,R
89.R90,R91
Chip
Resistor,15K,5%,CR0805
Panasonic ERJ6GEYJ153V
R9
Chip
Resistor,22,5%,CR0805
Panasonic ERJ6GEYJ220V
R10,R12,R1
3,R14,R39,R
58,R70
Chip
Resistor,220,5%,CR0805
Panasonic ERJ6GEYJ221V
R92-R95
Chip
Resistor,27,5%,CR0805
Panasonic ERJ6GEYJ270V
R20,R44,R5
7,R71
Chip
Resistor,2.7K,5%,CR0805
Panasonic ERJ6GEYJ272V
Table 18. Baseboard Bill of Materials (Sheet 3 of 5)
Rev. 1.7
Reference
Designator
Description Manufacturer
Manufacturer
P/N
Comments/
Changes
from
Rev D
Alternate
Manufacturing
Info
All
Changes
