Intel Bay Trail Series User Manual

21
The optional settings are: [Suspend Disabled]; [S3 (Suspend to RAM)].
EUP Function
The optional settings: [Disabled]; [Enabled].
This item should be set as [Disabled] if you wish to have all active wake-up
functions.
Wake-Up by PCIE/LAN from S5
The optional settings: [Disabled]; [Enabled].
*This function is supported when EUP Function is set as [Disabled].
Wake-Up by PS/2 Keyboard
The optional settings: [Disabled]; [Enabled].
Use this function to enable or disable PS/2 keyboard wake-up from S3/S4/S5.
*This function is supported when EUP Function is set as [Disabled].
Wake-Up by PS/2 Mouse
The optional settings: [Disabled]; [Enabled].
Use this function to enable or disable PS/2 mouse wake-up from S3/S4/S5.
*This function is supported when EUP Function is set as [Disabled].
PWRON After PWR-Fail
The optional settings are: [Former-Sts]; [Always on]; [Always off].
*This function is supported when EUP Function is set as [Disabled].
RTC WakeUp
The optional settings: [Disabled]; [Fixed Time]; [Dynamic Time].
Use this item to enable or disable system wake on alarm event.
When set as [Fixed Time], system will wake on the hour/min/sec specified.
When set as [Dynamic Time], system will wake on the current time + increased
minute(s).
*This function is supported when EUP Function is set as [Disabled].
 Super I/O Configuration
Press [Enter] to make settings for the following sub-items:
Super IO Configuration
 Serial Port 1 Configuration
Press [Enter] to make settings for the following items:
Serial Port 1 Configuration
Serial Port

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
