Intel Bay Trail Series User Manual

22
Use this item to enable or disable serial port (COM).
Change Settings
Use this item to select an optimal setting for super IO device.
WatchDog Timer
The optional settings: [Disabled]; [Enabled].
Use this item to enable or disable WatchDog Timer Control.
When set as [Enabled], the following sub-items shall appear:
WatchDog Timer Value
User can set a value in the range of [4] to [255].
WatchDog Timer Unit
The optional settings are: [Sec.]; [Min.].
 H/W Monitor
Press [Enter] to view current PC health status & system working status and make
further settings in ‘CPUFAN Smart Mode’:
CPUFAN Smart Mode
The optional settings are: [Disabled]; [Enabled].
When set as [Enabled], the following sub-items shall appear:
CPUFAN Full-Speed Temperature
Use this item to set CPUFAN full speed temperature. Fan will run at full speed
when temperature is higher than this preset limit.
CPUFAN Idle-Speed Temperature
Use this item to set CPUFAN idle speed temperature. Fan will run at idle speed
when temperature is lower than this preset limit.
 CPU Configuration
Press [Enter] to view current CPU configuration and make settings for the following
sub-items:
Active Processor Cores
Use this item to set the number of cores to enable in each processor packages.
Limit CPUID Maximum
The optional settings: [Disabled]; [Enabled].
This item should be set as [Disabled] for Windows XP.
Execute Disable Bit
The optional settings: [Disabled]; [Enabled].

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
