Intel Bay Trail Series User Manual

27
DVMT Pre-Allocated
Use this item to select DVMT 5.0 pre-allocated (fixed) graphics memory size used
by the internal graphics device.
The optional settings are: [64M]; [128M]; [256M]; [512M].
DVMT Total Gfx Mem
Use this item to select DVMT 5.0 total graphics memory size used by the internal
graphics device.
The optional settings are: [128M]; [256M]; [MAX].
Spread Spectrum Clock
The optional settings are: [Enabled]; [Disabled].
RC6(Render Standby)
Use this item to enable or disable render standby support.
Primary IGFX Boot Display
Use this item to select the video device which will be activated during POST.
The optional settings are: [VBIOS Default]; [CRT]; [DVI]; [LVDS].
LVDS Support
The optional settings are: [Enabled]; [Disabled].
*When set as [Enabled], user can make further settings in ‘LVDS Panel Type’.
LVDS Panel Type
Use this item to select LVDS panel used by Internal Graphics Device by selecting
the appropriate setup item.
The optional settings are: [640 X 480 @60Hz 18Bit]; [800 X 600 @60Hz 18Bit];
[1024 X 600 @60Hz 18Bit]; [1024 X 768 @60Hz 24Bit]; [1280 X 720 @60Hz 18Bit];
[800 X 480 @60Hz 18Bit]; [1366 X 768 @60Hz 18Bit]; [1440 X 900 @60Hz 18Bit];
[1366 X 768 @60Hz 24Bit]; [1440 X 900 @60Hz 24Bit]; [1280 X 1024 @60Hz
24Bit]; [1440 X 1050 @60Hz 24Bit]; [1600 X 900 @60Hz 24Bit]; [1680 X 1050
@60Hz 24Bit]; [1600 X 1200 @60Hz 24Bit]; [1920 X 1080@60Hz 24Bit].
 South Bridge
Press [Enter] to make settings for the following sub-items:
Onboard PCIE Lan Device
Use this item to enable or disable the PCI Express port 2 in the chipset.
The optional settings are: [Enabled]; [Disabled].

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
