Intel Bay Trail Series User Manual

28
Onboard Lan BootROM
Use this item to enable or disable boot option ROM for onboard network
devices.
The optional settings are: [Enabled]; [Disabled].
Mini PCIE
Use this item to enable or disable the PCI Express port 3 in the chipset.
The optional settings are: [Enabled]; [Disabled].
Speed
Use this item to configure PCIE port speed.
The optional settings are: [Auto]; [Gen2]; [Gen1].
USB 3.0 (XHCI) Support
In the case that ‘OS selection’ is set as [Windows 7], XHCI & EHCI mode will be
auto configuration.
The optional settings are: [Enabled]; [Disabled].
* Note: When set as [Disable], ‘USB 2.0 (EHCI) Support’ is applicable, for user to
make further settings.
USB 2.0 (EHCI) Support
In the case that ‘OS selection’ is set as [Windows 7], XHCI & EHCI mode will be
auto configuration.
The optional settings are: [Enabled]; [Disabled].
This item controls the USB EHCI (USB 2.0) functions. One EHCI controller must
always be enabled.
* Note: When set as [Enabled], ‘USB 3.0 (XHCI) Support’ is applicable, for user to
make further settings.
Audio Controller
Use this item to control the detection of the Azalia HD Audio device.
The optional settings are: [Disabled]; [Enabled].
[Disabled]: Azalia will be unconditionally disabled;
[Enabled]: Azalia will be unconditionally enabled;
When set as [Enabled], user can make settings in ‘Azalia HDMI Codec
’ that appears:
Azalia HDMI Codec
Use this item to enable or disable internal HDMI codec for Azalia.
The optional settings are: [Enabled]; [Disabled].

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
