Intel Desktop Board D945GTP Technical Product Specification
26
1.5.4 Real-Time Clock, CMOS SRAM, and Battery
A coin-cell battery (CR2032) powers the real-time clock and CMOS memory. When the computer
is not plugged into a wall socket, the battery has an estimated life of three years. When the
computer is plugged in, the standby current from the power supply extends the life of the battery.
The clock is accurate to ± 13 minutes/year at 25 ºC with 3.3 VSB applied.
NOTE
If the battery and AC power fail, custom defaults, if previously saved, will be loaded into CMOS
RAM at power-on.
1.6 PCI Express* Connectors
The board provides the following PCI Express connectors:
• One PCI Express x16 connector supporting simultaneous transfer speeds up to 8 GBytes/sec
• One PCI Express x1 connector. The x1 interface supports simultaneous transfer speeds up to
500 MBytes/sec
The PCI Express interface supports the PCI Conventional bus configuration mechanism so that the
underlying PCI Express architecture is compatible with PCI Conventional compliant operating
systems. Additional features of the PCI Express interface include the following:
• Support for the PCI Express enhanced configuration mechanism
• Automatic discovery, link training, and initialization
• Support for Active State Power Management (ASPM)
• SMBus 2.0 support
• Wake# signal supporting wake events from ACPI S1, S3, S4, or S5
• Software compatible with the PCI Power Management Event (PME) mechanism defined in the
PCI Power Management Specification Rev. 1.1
1.7 IEEE-1394a Connectors (Optional)
The optional IEEE-1394a interface addresses interconnection of both computer peripherals and
consumer electronics. The IEEE-1394a interface provides a throughput ranging from
100 Mbits/sec to 400 Mbits/sec. As a manufacturing option, the board includes three IEEE-1394a
connectors as follows:
• One IEEE-1394a connector located on the back panel.
• Two IEEE-1394a front-panel connectors located on the component side.
For information about Refer to
The location of the back panel IEEE-1394a connector Figure 18, page 54
The location of the front panel IEEE-1394a connectors Figure 20, page 56
The signal names of the front panel IEEE-1394a connectors Section 2.8.2.6, page 64
