Intel BLKD945GTPL User Manual

Technical Reference
57
Table 18 lists the component-side connectors identified in Figure 20.
Table 18. Component-side Connectors Shown in Figure 20
Item/callout
from Figure 20 Description
A
PCI Express x1 bus add-in card connector
B
Front panel audio connector
C
PCI Conventional bus add-in card connector 2
D
PCI Conventional bus add-in card connector 1
E
PCI Express x16 bus add-in card connector
F
Rear chassis fan connector
G
+12V power connector (ATX12V)
H
Processor fan connector
I
SCSI LED connector (optional)
J
Power connector
K
Diskette drive connector
L
Parallel ATA IDE connector
M
Serial ATA connector 3
N
Front chassis fan connector
O
Serial ATA connector 2
P
Serial ATA connector 0
Q
Auxiliary front panel power LED connector
R
Front panel connector
S
Serial ATA connector 1
T
Front panel USB connector
U
Chassis intrusion connector
V
Front panel USB connector
W
Front panel IEEE-1394a connector (optional)
X
Front panel IEEE-1394a connector (optional)
