Technical Reference
59
Table 23. Processor Fan Connector
Pin Signal Name
1 Ground
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
Table 24. Front and Rear Chassis Fan Connectors
Pin Signal Name
1 FAN_CONTROL
2 +12 V
3 FAN_TACH
