Intel Desktop Board DP43BF Technical Product Specification
12
Table 2. Feature Summary
LAN Support Gigabit (10/100/1000 Mb/s) LAN subsystem using the Broadcom* BCM57788
Gigabit Ethernet Controller
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.3
• Support for PCI Express* Revision 1.1
• Suspend to RAM support
• Wake on PCI, PCI Express, PS/2 devices, serial port, front panel, USB ports,
and LAN
Expansion
Capabilities
• One PCI Express 2.0 x16 bus add-in card connector
• Two PCI Express 1.0 x1 bus add-in card connectors
• Four Conventional PCI bus add-in card connectors
Hardware Monitor
Subsystem
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Three fan sense inputs used to monitor fan activity
