Intel Desktop Board DP43BF Technical Product Specification
48
Table 18. Chassis Intrusion Header
Pin Signal Name
1 Intruder#
2 Ground
Table 19. Processor (4-Pin) Fan Header
Pin Signal Name
1 Ground
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
Table 20. Front, Rear, and Auxiliary Chassis Fan Headers
Pin 4-Wire Support Pin 3-Wire Support
1 Ground 3 Ground
2 +12 V 2 FAN_POWER
3 FAN_TACH 1 FAN_TACH
4 FAN_CONTROL N/A N/A
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• PCI Express 2.0 x16: one PCI Express 2.0 x16 connector supporting simultaneous
transfer speeds up to 8 GB/s of peak bandwidth per direction and up to 16 GB/s
concurrent bandwidth.
• PCI Express 1.1 x1: two PCI Express 1.1 x1 connectors. The x1 interface
supports simultaneous transfer speeds up to 250 MB/s of peak bandwidth per
direction and up to 2 GB/s concurrent bandwidth.
• Conventional PCI (rev 2.3 compliant) bus: four Conventional PCI bus add-in card
connectors.
Note the following considerations for the Conventional PCI bus connectors:
• The Conventional PCI bus connectors are bus master capable.
• SMBus signals are routed to the Conventional PCI bus connectors. This enables
Conventional PCI bus add-in boards with SMBus support to access sensor data on
the desktop board. The specific SMBus signals are as follows:
⎯ The SMBus clock line is connected to pin A40.
⎯ The SMBus data line is connected to pin A41.
