Intel BLKDP43BF - S;PDIF Header

Technical Reference
47
Table 16. PATA Connector (44-Pin)
Pin Signal Name Pin Signal Name
1 #Reset 2 GND
3 Data 7 4 Data 8
5 Data 6 6 Data 9
7 Data 5 8 Data 10
9 Data 4 10 Data 11
11 Data 3 12 Data 12
13 Data 2 14 Data 13
15 Data 1 16 Data 14
17 Data 0 18 Data 15
19 GND 20 Key (no pin)
21 DMA Request 22 GND
23 #IOW 24 GND
25 #IOR 26 GND
27 IO Chrdy 28 Cable Select
29 DMA Acknowledge 30 GND
31 IRQ14 32 #IOCS16
33 Addr 1 34 Passed Diagnostics
35 Addr 0 36 Addr 2
37 #CS0 (1F0-1F7) 38 #CS1 (3f6-3f7)
39 #Active (LED driver) 40 GND
41 +5V_DC (logic) 42 +5V_DC (motor)
43 GND 44 Type (GND = ATA)
Table 17. S/PDIF Header
Pin Signal Name
1 Ground
2 S/PDIF out
3 Key (no pin)
4 +5 VDC
