1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 2 summarizes the major features of Intel Desktop Board DP43BF.
Table 2. Feature Summary
Form Factor ATX (9.60 inches by 11.60 inches [243.84 millimeters by 294.64 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Quad processor Q6000/Q8000/Q9000 Series in an LGA775
socket
• Intel
®
Core™2 Duo processor E4000/E6000/E7000/E8000 Series in an LGA775
socket
• Intel
®
Pentium
®
Dual-Core processor E2000/E5000 Series in an LGA775 socket
• Intel
®
Celeron
®
Dual-Core processor 400/1000 Series in an LGA775 socket
• Intel
®
Xeon
®
processor 3000/X3000 Series in an LGA775 socket
Memory
• Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for up to 8 GB of system memory using non-ECC DDR3 800, 1066, or
1333 (OC) MHz DIMMs
Chipset
Intel
®
P43 Express Chipset, consisting of:
• Intel
®
82P43 Graphics and Memory Controller Hub (MCH)
• Intel
®
82801JIR I/O Controller Hub (Intel ICH10R)
Audio 10-channel (7.1 + 2) audio subsystem using Realtek ALC888S-VC high definition
audio codec
Legacy I/O Control ITE IT8721F based legacy I/O controller for hardware management and serial and
PS/2* ports
Peripheral
Interfaces
• Twelve USB 2.0 ports:
― Six ports are implemented with stacked back panel connectors
― Six ports are routed to three separate front panel headers
• Two IEEE 1394a ports:
― One back panel port
― One front panel header
• Five internal Serial ATA (SATA) interfaces
• One external Serial ATA (eSATA) interface
• One Parallel ATA (PATA) connector
• One serial port header
• PS/2 keyboard/mouse ports on the back panel
continued
