Product Description
21
1.6 Intel
®
P43 Express Chipset
The Intel P43 Express chipset consists of the following devices:
Intel 82P43 Memory Controller Hub (MCH) with Direct Media Interface (DMI)
interconnect
Intel 82801JIR I/O Controller Hub (ICH10R)
The MCH component provides interfaces to the CPU, memory, PCI Express, and the
DMI interconnect. The ICH10R is a centralized controller for the board’s I/O paths.
The chipset supports the following features:
USB
Serial ATA
Parallel ATA
For information about Refer to
The Intel P43 Express chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.6.1.1 PCI Express x16 Graphics
The MCH also supports an add-in discrete graphics card through the PCI Express 2.0
graphics connector.
PCI Express 2.0 x16:
Supports PCI Express GEN1 frequency of 1.25 GHz resulting in 2.5 Gb/s each
direction (500 MB/s total). Maximum theoretical bandwidth on interface of
4 GB/s in each direction simultaneously, for an aggregate of 8 GB/s when
operating in x16 mode.
Supports PCI Express GEN2 frequency of 2.5 GHz resulting in 5.0 Gb/s each
direction (1000 MB/s total). Maximum theoretical bandwidth on interface of
8 GB/s in each direction simultaneously, for an aggregate of 16 GB/s when
operating in x16 mode.
For information about Refer to
PCI Express technology http://www.pcisig.com
1.6.2 USB
The board supports up to twelve USB 2.0 ports, supports UHCI and EHCI, and uses
UHCI- and EHCI-compatible drivers.
The Intel ICH10R provides the USB controller for all ports. The port arrangement is as
follows:
Six ports are implemented with stacked back panel connectors
Six ports are routed to three separate front panel USB headers
For information about Refer to
The location of the USB connectors on the back panel Figure 9, page 43
The location of the front panel USB headers Figure 10, page 44
