Intel Desktop Board DP43BF Technical Product Specification
14
Table 3. Board Components Shown in Figure 1
Item/callout
from Figure 1 Descript
ion
A Conventional PCI bus add-in card connector
B S/PDIF audio header
C Conventional PCI bus add-in card connector
D Conventional PCI bus add-in card connector
E Conventional PCI bus add-in card connector
F Speaker
G PCI Express x1 connector
H PCI Express x16 connector
I Conventional PCI bus add-in card connector
J Battery
K Back panel connectors
L Front panel IEEE 1394a header
M Processor core power connector (2 x 2)
N Rear chassis fan header
O LGA775 processor socket
P Intel 82P43 MCH
Q Processor fan header
R DIMM Channel A sockets
S DIMM Channel B sockets
T BIOS setup configuration jumper block
U Front panel header
V Alternate front panel Power LED header
W Main power connector (2 x 12)
X Parallel ATA connector
Y Front chassis fan header
Z Standby power LED
AA Intel 82801JIR I/O Controller Hub (Intel ICH10R)
BB Auxiliary chassis fan header
CC Serial ATA connectors (5)
DD Front panel USB headers
EE Intel
®
High Definition Audio Link header
FF Chassis intrusion header
GG Serial port header
HH Front panel audio header
