Technical Reference
45
Table 11 lists the component-side connectors and headers identified in Figure 10.
Table 11. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A Conventional PCI bus add-in card connector
B S/PDIF header
C Conventional PCI bus add-in card connector
D Conventional PCI bus add-in card connector
E Conventional PCI bus add-in card connector
F PCI Express x1 connector
G PCI Express x16 connector
H PCI Express x1 connector
I Front panel IEEE 1394a header
J Processor core power connector (2 x 2)
K Rear chassis fan header
L Processor fan header
M Front panel header
N Alternate front panel Power LED header
O Main power connector (2 x 12)
P Parallel ATA connector
Q Front chassis fan header
R Auxiliary chassis fan header
S Serial ATA connectors (5)
T Front panel USB header
U Front panel USB header
V Front panel USB header
W Intel High Definition Audio Link header
X Chassis intrusion header
Y Serial port header
Z Front panel audio header
