Intel Desktop Board DQ45CB Product Guide
12
Table 2. Intel Desktop Board DQ45CB Components
Label Description
A Front panel audio header
B PCI bus connector
C PCI Express x1 connector 2
D PCI Express x16 connector
E PCI Express x1 connector 1
F Rear chassis fan header (3-pin)
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin)
I Serial header
J Processor socket
K Processor fan header (4-pin)
L Main power connector (2 x 12 pin)
M DDR2 DIMM 0 sockets
N DDR2 DIMM 1 sockets
O Front chassis fan header (3-pin)
P Battery
Q Chassis intrusion header
R Alternate front panel power LED header
S Front panel header
T BIOS configuration jumper block
U Serial ATA connectors (5)
V Speaker
W High-speed USB 2.0 headers (3)
X IEEE 1394a header
Y HD audio link header
For more information about Intel Desktop Board DQ45CB, go to
http://intel.com/design/motherbd.
