Intel Desktop Board DQ45CB Product Guide
18
Table 4 describes the LED states when the board is powered up and the LAN
subsystem is operating.
Table 4. LAN Connector LEDs
LED LED Color LED State Indicates
A (Link) Off LAN link is not established
Green
On LAN link is established
Blinking LAN activity is occurring
N/A Off 10 Mb/s data rate
Green On 100 Mb/s data rate
B (Speed)
Yellow On 1000 Mb/s data rate
Intel
®
Active Management Technology
(Intel
®
AMT) 5.0
Intel AMT 5.0 offers IT organizations tamper-resistant and persistent management
capabilities. Intel AMT is a hardware-based solution that uses out of band
communication to manage access to client systems in addition to offering encrypted
and persistent asset management and remote diagnostics and/or recovery capabilities
for networked platforms. With Intel AMT, IT organizations can easily get accurate
platform information, and can perform remote updating, diagnostics, debugging and
repair of a system, regardless of the state of the operating system or the power state
of the system.
The Intel AMT subsystem consists of:
• ARC4 microcontroller embedded in the Intel 82Q45 GMCH
• ICH10DO (Intel
®
Management Engine function)
• Intel 82567LM Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
• Channel A DIMM(s)
• BIOS/SPI Flash
• On-board Intel AMT status indicator
NOTE
Software with Intel AMT capability is required to take advantage of the Intel AMT
platform management capabilities.
