Intel Desktop Board DQ45CB Product Guide
14
NOTE
System resources and hardware (such as PCI Express) require physical memory
address locations that can reduce available addressable system memory. This could
result in a reduction of as much as 1 GB or more of physical addressable memory
being available to the operating system and applications, depending on the system
configuration and operating system.
Go to the following locations for more information about:
• SDRAM specifications, http://intel.com/technology/memory/
• Installing memory, page 38 in Chapter 2
• Tested memory, http:
//cmtlabs.com/mbsearch.asp
Intel
®
Q45 Express Chipset
The Intel Q45 Express Chipset consists of the following devices:
• Intel 82Q45 Express Chipset Graphics and Memory Controller Hub (GMCH) with
Direct Media Interface (DMI)
• Intel 82801JDO I/O Controller Hub (ICH10DO) with DMI
The GMCH component provides interfaces to the processor, memory, PCI Express, and
the DMI interconnect. The component also provides integrated graphics capabilities
supporting 3D, 2D, and display capabilities. The ICH10DO is a centralized controller
for the board’s I/O paths.
For more information on the Intel Q45 Express Chipset go to
http://developer.intel.com/products/chipsets/
Intel Q45 Graphics Subsystem
The Intel Q45 Express Chipset provides DVI-D and DVI-I support via the integrated
Intel Graphics Media Accelerator 4500 (GMA 4500) graphics controller.
The Intel GMA 4500 graphics controller has the following features:
• Advanced graphics performance, including:
⎯ DirectX10.0* and OpenGL* 2.0 compliant
⎯ Shader Model 4.0 support
• Enhanced video playback support, including:
⎯ Support for playback of Blu-ray Disc* technology DVDs
Microsoft Windows Vista* only
Hardware acceleration supported for MPEG-2 only
⎯ Software DVD at 30 fps full screen
⎯ Dynamic Video Memory Technology (DVMT) 5.0
