Pin (3-4) of JAT_COPEN (4-pin): Case Open Message Display Function Select
Pin (1&2) of JAT_COPEN → Case Open
3
Pin 1
2
4
3-4 Open: Normal (Default);
;
Pin 1
3
2
4
3-4 Closed: Case Open Function
Selected(One Touch).
Pin 1-2 Close: When Case open function pin short to GND, the Case open function
was detected. When Used, needs to enter BIOS and enable
‘
Case Open Detect
’
function. In this case if your case is removed, next time when you restart your computer,
a message will be displayed on screen to inform you of this.
Pin (1-2) of JBAT (8-pin): Flash Descriptor Security Override
(2.54 pitch)
Pin 1-2 of JBAT → Flash Desciptor Security Override
2
Pin 1
1-2 Open: Normal (Default);
Pin 1
1-2 Closed: Flash Descriptor Security Override.
2
