19
(5) FP_USB20 (9-pin): USB 2.0 Port Header
(2.54 pitch)
Pin 1
VCC
-DATA
GND
+DATA
VCC
NC
C
-DATA
GND
+DATA
(6) PS2KBMS (6-pin): PS2 Keyboard & Mouse Header
(2.54 pitch)
GND
KB_CLK
KB_DATA
Pin1
MS_DATA
VCC
MS_CLK
