Intel D101GGC User Manual

iii
Preface
This Product Guide gives information about board layout, component installation, and regulatory
requirements for Intel
®
Desktop Board D101GGC.
Intended Audience
The Product Guide is intended for technically qualified personnel. It is not intended for general
audiences.
Intended Uses
All Intel desktop boards are evaluated as Information Technology Equipment (I.T.E.) for use in
personal computers (PC) for installation in homes, offices, schools, computer rooms, and similar
locations. The suitability of this product for other PC or embedded non-PC applications or other
environments, such as medical, industrial, alarm systems, test equipment, etc. may not be supported
without further evaluation by Intel.
Information Layout
The chapters in this Product Guide are arranged as follows:
31 Desktop Board Features: a summary of product features
32 Installing and Replacing Desktop Board Components: instructions on how to install the desktop
board and other hardware components
4A Regulatory Compliance: safety and EMC regulations, product certification
Conventions
The following conventions are used in this manual:
CAUTION
Cautions warn the user about how to prevent damage to hardware or loss of data.
NOTE
Notes call attention to important information.

Intel D101GGC Specifications

General

Form Factor	Micro ATX
Chipset	ATI Radeon Xpress 200
Socket	LGA 775
Memory Type	DDR
Memory Slots	4
Expansion Slots	1 x PCIe x16, 2 x PCI
Storage Interface	SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel
