1.8.1 Audio Connectors
1.8.1.1 CD-ROM (Legacy-style 2-mm) Audio Connector
A 1 x 4-pin legacy-style 2-mm connector connects an internal CD-ROM drive to the audio mixer.
For information about Refer to
The location of the legacy-style 2-mm connector Figure 9, page 54
The signal names of the legacy-style 2-mm connector Table 38, page 57
1.8.1.2 ATAPI CD-ROM Audio Connector
A 1 x 4-pin ATAPI-style connector connects an internal ATAPI CD-ROM drive to the audio
mixer.
For information about Refer to
The location of the ATAPI CD-ROM connector Figure 9, page 54
The signal names of the ATAPI CD-ROM connector Table 26, page 55
1.8.1.3 Auxiliary Line In Connector
A 1 x 4-pin ATAPI-style connector connects the left and right channel signals of an internal audio
device to the audio subsystem.
For information about Refer to
The location of the auxiliary line in connector Figure 9, page 54
The signal names of the auxiliary line in connector Table 25, page 55
1.8.2 Audio Subsystem Software
Audio software and drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining audio software and drivers Section 1.2, page 16
