Table 12. I/O Map (continued)
Address (hex) Size Description
96 contiguous bytes starting on a 128-byte
divisible boundary
ICH2 (ACPI + TCO)
64 contiguous bytes starting on a 64-byte
divisible boundary
D850GB board resource
64 contiguous bytes starting on a 64-byte
divisible boundary
Onboard audio controller
32 contiguous bytes starting on a 32-byte
divisible boundary
ICH2 (USB controller #1)
16 contiguous bytes starting on a 16-byte
divisible boundary
ICH2 (SMBus)
4096 contiguous bytes starting on a 4096-byte
divisible boundary
Intel 82801BA PCI bridge
256 contiguous bytes starting on a 256-byte
divisible boundary
ICH2 audio mixer
64 contiguous bytes starting on a 64-byte
divisible boundary
ICH2 audio bus mixer
256 contiguous bytes starting on a 256-byte
divisible boundary
ICH2 modem mixer
32 contiguous bytes starting on a 32-byte
divisible boundary
ICH2 (USB controller #2)
96 contiguous bytes starting on a 128-byte
divisible boundary
LPC47M102
* Default, but can be changed to another address range.
** Dword access only.
*** Byte access only.
✏ NOTE
Some additional I/O addresses are not available due to ICH2 address aliassing. For information
about the ICH2 addressing, refer to Section 1.2 on page 16.
