Intel D945PLNM - Board Components Shown in Figure 1

Product Description
13
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A
Audio codec
B
Front panel audio connector
C
Ethernet device
D
PCI Conventional bus add-in card connectors [2]
E
PCI Express x16 bus add-in card connector
F
Back panel connectors
G
+12V power connector (ATX12V)
H
Rear chassis fan connector
I
LGA775 processor socket
J
Intel 82945PL MCH
K
Processor fan connector
L
DIMM Channel A socket
M
DIMM Channel B socket
N
Legacy I/O controller
O
Power connector
P
Diskette drive connector
Q
Parallel ATE IDE connector
R
Battery
S
Front chassis fan connector
T
BIOS Setup configuration jumper block
U
Serial ATA connectors [4]
V
Auxiliary front panel power LED connector
W
Front panel connector
X
Front panel USB connectors [2]
Y
Chassis intrusion connector
Z
Intel 82801G I/O Controller Hub (ICH7)
AA
SPI flash device
BB
Speaker
CC
PCI Express x1 bus add-in card connector
