Table 15. Component-side Connectors Shown in Figure 13
Item/callout
from Figure 13 Description
A
PCI Express x1 bus add-in card connector
B
Front panel audio connector
C
PCI Conventional bus add-in card connector 2
D
PCI Conventional bus add-in card connector 1
E
PCI Express x16 bus add-in card connector
F
Rear chassis fan connector
G
+12V power connector (ATX12V)
H
Processor fan connector
I
Power connector
J
Diskette drive connector
K
Parallel ATA IDE connector
L
Serial ATA connector 3
M
Front chassis fan connector
N
Serial ATA connector 2
O
Serial ATA connector 0
P
Auxiliary front panel power LED connector
Q
Front panel connector
R
Serial ATA connector 1
S
Front panel USB connector
T
Chassis intrusion connector
U
Front panel USB connector
